KEY FEATURES: · Type: Thrubeam (through-beam) · Shape: Rectangular · Output: NPN · Connection: Cable (2 m) · Detecting Distance: Up to 20 meters · Light Source: Red LED · Sensitivity Adjustment: 1-turn trimmer (230°) · Response Time: 500 µs · Operation Mode: LIGHT-ON/DARK-ON (switch-selectable) · Indicators (LED): 1. Power (T): Orange LED 2. Output (R): Orange LED 3. Stable operation: Green LED 4. Light receiving: Red LED 5. · Control Output: Open collector output, 30 V max., 100 mA max., Residual voltage: 1 V max. · Protection Circuit: Reversed polarity, overcurrent protection, surge absorber · Interference Suppression: Up to 2 units (when polarization filters are attached) · Power Voltage: 10 to 30 VDC, including Ripple (P-P) 10% · Current Consumption: 1. Transmitter: 20 mA or less 2. Receiver: 28 mA or less · Environmental Resistance: 1. Enclosure Rating: IEC: IP67/NEMA: 4A, 6, 12/DIN: IP69K 2. Ambient Light: Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max. 3. Ambient Temperature: -20 to +55 °C (No freezing) 4. Relative Humidity: 35 to 85 % RH (No condensation) 5. Vibration Resistance: 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions 6. Shock Resistance: 1,000 m/s², 6 times in each of the X, Y, and Z directions · Material: 1. Housing: Glass-fiber reinforced PBT 2. Lens Cover: Polyarylate (PAR) 3. Trimmer: Glass-fiber reinforced polyamide (PA) 4. Case Connection: Screw: Nickel-plated iron and zinc, packing: nitrile butadiene rubber (NBR) 5. Cable: Polyvinyl chloride (PVC) · Weight: Approximately 60 g​ >> Fedex Ground Shipping Condition Warranty Shipping & Handling Payment Methods Very good unless stated otherwise in the description 30 days PRICE DEPENDS ON PRODUCT WEIGHT RECEIVE 7-14 DAYS PAYONEER / PAYPAL Terms & Conditions l Payment must be received within 7 days after auction closing. We ship every business day l Some used items may have cosmetic imperfections such as scratches, ink markings, etc., which do not in any way affect the functionality or performance of the unit. l Products are tested and fully functional before shipping. AS-IS items are not tested and will not be covered under warranty, unless otherwise stated. l Damage caused by misuse or improper handling by the buyer will not be covered under warranty. l Any presumed defective units must obtain an RMA # before return. l Item returned will be tested. If found defective, either a replacement or a refund will be sent immediately. If found not to be defective or damage caused by misuse or improper handling, item will be returned at buyers expense. l International order will ship via FEDEX or DHL or POSLAJU provide with tracking number and informations together. IFS: 3M
